Vector Addition Calculator

Vectors represent quantities possessing both magnitude and direction. When adding two vectors, say Vector A and Vector B, you combine their corresponding components along each spatial axis. For 2D vectors defined by Cartesian coordinates, the sum is calculated as v_sum = (αA_x + βB_x, αA_y + βB_y), where α and β are scalar multipliers. For 3D vectors, this principle extends to the z-axis. To find the resulting magnitude, the calculator applies the Pythagorean theorem: |v| = √(x² + y² + z²). Direction angles are extracted using the four-quadrant inverse tangent function, atan2(y, x), ensuring absolute angular precision.

Let us walk through adding two 2D vectors: Vector A = (3, 4) and Vector B = (1, 2) with standard scalar multipliers of α = 1 and β = 1. First, we add their respective x-components: 3 + 1 = 4. Next, we add their y-components: 4 + 2 = 6. This gives us our vector sum components: (4, 6). To find the magnitude of this resulting vector, we compute the square root of the sum of the squared components: √(4² + 6²) = √(16 + 36) = √52 ≈ 7.21. Finally, the direction angle is calculated using atan2(6, 4), which yields approximately 56.31 degrees.

Always verify your coordinate system and input units before running computations, as mixing polar forms (magnitude and angle) with Cartesian forms (x and y components) requires careful conversion. Pay close attention to scalar multiples (α and β); if you need standard addition, keep both multipliers at 1, but adjust them if you are computing linear combinations or net forces with opposing directions. Finally, keep track of dimensional constraints—ensure you aren't attempting to combine 2D calculations with 3D axes unless explicitly projecting into higher dimensions.
